Poromix

POROMIX is a lightweight, 100% natural & environment friendly. It is very easy to use- just add water and it is ready. It gives versatility in design and high performance at a reasonable cost. POROMIX can be applied over a variety of roof slab or metal deck.

• Advantages
• Areas of application
• Application method
• Technical aspects

Advantages

• Reduces A.C. power consumption up to 35%
• It reduces unwanted heat flow
• Increase building comfort
• Need no maintenance
• Retains insulating property life long
• Everlasting with the building
• Fire resistive thermal barrier
• Simple application
• Smoother Finish
• Convenient packing Of 25kg
• Good compressive strength
• Economical

• Residential buildings
• Commercial complexes
• R&D centres
• High rise buildings
• Pharmaceuticals
• Textile units
• Automotive plants
• Power plants

• Corporate
• Offices
• Hotels
• Resorts
• Cold Storage
• Daries
• Breweries etc.

• POROMIX can be laid over the RCC slab requisite water (approx. 30 litres/25 kg bag) should be added to dry POROMIX
• Layer has to be laid over the RCC Slab, steel deck etc.
• Water curing is required thrice a day in summer and twice a day in winter for 4 to 6 days.
• Over POROMIX slab, a water proofing layer is a must.

Poromix usage chart

Layer thickness	U Value achieved in BTU/(Hr)(°)Ft)	Consumption per Sq.ft. in kg.	Approx. Reduction in Heat Transmission rate through RCC Slab in %
2” (50mm)	0.18	2	62
3” (75 mm)	0.14	3	70
4” (100 mm)	0.11	4	77
#Considering rate of heat transmission U value = 0.47 BTU/(Hr)(°F)(Ft)2 for 4" (100 mm) thick RCC slab.

Minimum compressive strength	4 MPa per sq.mtr.
Maximum oven dry density	480 kg per cu.mtr.
K value	0.12 W/mK
R value	1.2 per inch thickness
